AirMax AirPrism 5GHz 3x30 HD Sector

Ubiquiti Networks introduces an innovative sector antenna for your Point-to-MultiPoint (PtMP) applications, the airPrism 5 GHz 3x30 HD Sector Antenna. The AirPrism antenna features significant advances in noise isolation and beam performance to complement the Rocket5ac Prism radios (not included) for co-location deployments. Three Rocket5ac Prism radios mounted on a single AirPrism antenna maximizes throughput in an efficient tower footprint, minimizing installation and tower costs. Highly resistant to noise interference, the airPrism antenna provides superior beam performance in high-density areas for high-capacity, multipoint networks. Specifications airPrism 5GHz 3x30 HD Sector Dimensions: 322.6 x 201.5 x 1300 mm (12.7 x 7.93 x 51.18") Weight: 13.1 kg (28.9 lb) Frequency Range: 5.15 - 5.85 GHz Gain: 22 dBi HPOL Beamwidth: 3 x 30 degrees (6 dB) VPOL Beamwidth: 3 x 30 degrees (6 dB) Electrical Beamwidth: 8 degrees Electrical Downtilt: 2 degrees Max. VSWR: 1.75:1 Polarization: Dual-Linear Cross-Polarization Isolation: 30 dB Min. Interfaces: (6) RP-SMA Connectors (Weatherproof ) Compatible Radio: Rocket5ac Prism, model R5AC-PRISM Wind Loading: 534 N @ 200 km/h (120 lbf @ 125 mph) Wind Survivability: 200 km/h (125 mph) Mounting: Universal Pole Mount, Rocket Bracket, and Weatherproof RF Connectors Included ETSI Specification: EN 302 326 DN2 Certifications: CE, FCC, IC Package Contents airPrism Antenna, Protective Shourds (3), U-brackets (2), Pole Brackets (2), Pole Clamps (2), Carriage Bolts (4), Hex Bolts with Washers (8), Serrated Flange Nuts (4), Hex Nuts (4), Quick Start Guide. * Indien dit product boven de toegestane limieten gebruikt wordt, is dit niet langer vergunningsvrij en zelfs illegaal (max zendvermogen: 100 mW op 2,4GHz en 200 mW op 5GHz). Wij raden u aan de standaard configuratie v.w.b. de landeninstelling en/of vermogensinstelling van de apparatuur niet te wijzigen. Het gebruik van meer dan het wettelijke toegestane vermogen kan leiden tot verminderde bruikbaarheid van WIFI in uw onmiddellijke omgeving.
