UniFi AC M Dual-Band Antenna UMA-D for UAP-AC-M

The UniFi Antenna, model UMA-D, is an optional mesh antenna designed to work with the UniFi AC Mesh AP, model UAP-AC-M. With dual-band support, the UMA-D expands range coverage and provides customized pattern shaping. Antenna Features Optimized for 802.11ac, the UMA-D offers a high efficiency directional radiation pattern with dual polarity. Weather-Resistant Enclosure Encased in UV-stabilized plastic, the UMA-D can be used indoors or outdoors. Versatile Mounting The UMA-D has a ball joint mount designed for precise aiming and can be mounted on a pole or wall. Compatibility The UMA-D is a connectorized antenna that is compatible with the UAP-AC-M. Specifications Dimensions: 201.3 x 128.0 x 32.5 mm (7.93 x 5.04 x 1.28") Weight: - (with Mount): 480 g (16.93 oz) - (without Mount): 400 g (14.11 oz) Enclosure: Outdoor UV Stabilized Plastic RF Connections: (2) RP-SMA Supported Frequency Range: 2.4 - 2.5 GHz, 5.1 - 5.9 GHz HPOL Beamwidth: - 2.4 GHz: 90 degrees - 5 GHz: 45 degrees VPOL Beamwidth: - 2.4 GHz: 90 degrees - 5 GHz: 45 degrees Elevation Beamwidth: - 90 degrees - 45 degrees Maximum VSWR: 2.5:1 Polarization: Dual-Linear Cross-Pol Isolation: - 2.4 GHz: 25 dB - 5 GHz: 30 dB Antenna Gain: - 2.4 GHz: 10 dBi - 5 GHz: 15 dBi Mounting: Wall/Pole (Kits Included) Package Contents UMA-D Antenna, Ball Join Mount, Lock Ringa, Screws (4), Screw Anchors (4), Hex Bolt, Wall Mount Plate, Metal Strap, RF Cables (2), Quick Start Guide.
